Cast Basalt Lined Pipes & Fittings Manufacturers











Cast Basalt is a mineral of exceptionally high abrasion resistance, unlimited resistance to moisture, high compressive strength and resistance to virtually all acids and alkalis and is completely corrosion free. Cast basalt is produced by melting selected natural basalt broken into sizes of 20-50 mm in shaft furnaces at temperatures around 1,300C, following by casting at which the melted basalt forms uniforms pherolithic crystals hence producing its typical physical properties, in particular its exceptional hardness and wear-resistance.

Cast basalt reaches a value of hardness of 8( min ) on the Moh's hardness scale. for comparision : the highest value10is only attained by dimonds. by virtue of these properties,the silicate cast basalt provides outstanding protection against abrasion and scrubbing.

However, it is marked by ascertain sensitivity ti impacts.Under Normal services conditions, cast basalt withstands temperatures up to approx.+ 350C or-40C. However Cast basalt should not be subjected ti temperature shocks.

Sizes : Cast basalt produces are manufactured as tiles, from pieces and segments. straight pipes are spun-cast, available for nominal bores of 32 to 600 mm with the wall thickness ranging from 20 to 30mm and a standard lenght of 500mm.samller nominal bores of straight pipes, pipe segment for radill of 40 to 3,000mm of vatrious angles, as well as special formpiece linings are pre dominately sand-cast. The standard wall-thickness is 20mm. depending on the respective quantity, steel moulds can also be used, the wall thickness in those cases usually being 30 to 40mm.
